XCD 2,8/135
The XCD 2,8/135 is a short telephoto lens providing a 135mm focal length. It compares to a 105mm full frame lens, making it perfect for portrait or landscape photography. The XCD 135mm features a 1 m close distance setting (1:5.8 and 1:3.4 image scale) and an aperture range between 2,8 and 32. When paired with the dedicated X Converter 1,7, the lens’ focal length grows to about 230mm, providing a 178mm full frame equivalency along with an aperture range of 4,8-55.
Like the other XCD Lenses, the XCD 2,8/135 features an integral central shutter, offering exposure times from 60 minutes to 1/2000s with full flash synchronisation.
The XCD 2,8/135 can be bought with or without the X Converter 1,7.
When purchasing the XCD 2,8/135 with the X Converter 1,7, the Tripod Mount Ring is included in the package.

XCD 2,8/135
Camera
X1D-50c
Shutter speed
3s
Aperture
f/4

XCD 2,8/135
Camera
X1D-50c
Shutter speed
8s
Aperture
f/5,6
XCD 2,8/135
Technical specifications
Aperture range
f/2,8 - f/32
Focal length
133 mm
Angle of view
23°/19°/14°
LENS DESIGN
10 elements
6 groups
*The final product may look slightly different compared to the attached product images.
XCD 2,8/135 + X Converter 1,7
Technical specifications
Aperture range
f/4,8 - f/55
Focal length
226 mm
Angle of view
14°/11°/8°
CONVERTER DESIGN
6 elements
4 groups

XCD 2,8/135
+ X CONVERTER 1,7
Camera
X1D-50c
Shutter speed
16s
Aperture
f/4,8
